Application: ProSeries™ Sand Control Solutions

proPACK®

proPACK®: Prepacked Rod Based Wire-Wrapped Screen

FET Variperm’s proPACK Prepacked Rod Based Screens are manufactured and installed as a self-supported concentric assembly with no base pipe.

FEATURES & BENEFITS

  • Diameters from 2” Pipe Size to 18” Pipe Size
  • 0.250” – 1.00” radial pack
  • Double re-sieved well rounded silica sand or carbo ceramic pack media
  • Slot size selected based on filter pack media sizing
  • 12-20, 16-30, 20-40 prepack media
  • Corrosion-resistant stainless steel (304L or 316L)
  • High flow rate with low-pressure drop
  • Erosion resistant

APPLICATIONS

  • Fine aquifer sands require filter media to achieve sand control
  • Alternative to gravel packing
  • High-rate water source wells
  • De-watering wells
  • Vertical and deviated water wells
  • Remedial screen completions

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to Downhole Sand Control

proWRAP®

proWRAP®: Rod-Based Wire-Wrapped Screen

FET Variperm’s proWRAP Rod-Based Screens are manufactured and installed as a self-supported assembly with no base pipe.

FEATURES & BENEFITS

  • Pipe Size and Telescope Screen options
  • Diameters from 3/8” Pipe Size to 18” Pipe Size/20” Telescope
  • Rib and Wrap wire combinations selected for each diameter to achieve desired flow rate, yield, and collapse strength
  • Slot sizes range from 0.004” to 0.500”
  • Corrosion-resistant stainless steel (304L or 316L)
  • Butt Weld fittings, NPT, F480, and other threaded connections available
  • High flow rate with low-pressure drop
  • Optimal for well development purposes

APPLICATIONS

  • High-rate water source wells
  • De-watering wells
  • Vertical and deviated water wells
  • Remedial screen completions

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back To Downhole Sand Control
proLab icon

proLAB™

proLAB™ Design & Testing Services

NEAR WELLBORE PHYSICS TESTING SERVICES

Variperms’s proLAB is an elite technical team dedicated to developing successful completions by focusing on near wellbore conditions and sand control strategies for optimized production. Variperms’s proLAB includes sand control and near wellbore physics experts with diverse industrial and academic background including physical modelling and experimental testing, petroleum geomechanics, rock mechanics and geotechnics.

Variperms’s proLAB offers a three-phase sand control design and testing program. This program seeks to evaluate sand control designs for PSD variations of a studied field, utilizing improved sand control testing methodologies.

Unlock the potential of your reservoir with proLAB™ Testing

PROLAB SERVICES

Variperm’s proLAB provides services for sand characterization and screen evaluation. The main services for sand characterization are:

SAND PARTICLE CHARACTERIZATION

  • Sonic sifter Particle Sand Distribution (PSD) analysis
  • Dynamic Image Analysis (DIA) (PSD and shape)
  • Scanning Electron Microscopy (SEM) and SEM-Energy Dispersive XRD (EDX) analysis

flow chart

SAND RETENTION TEST DIAGRAMS

Featuring our new, improved and proprietary version of what industry refers to as sand retention tests (SRT).

LSCE LINEAR-FLOW SAND CONTROL EVALUATION

LSCE LINEAR-FLOW SAND CONTROL EVALUATION

GRAVEL PACKING STANDALONE COMPLETION TESTING

GRAVEL PACKING STANDALONE COMPLETION TESTING

CASED AND PERFORATED STANDALONE COMPLETION TESTING

CASED AND PERFORATED STANDALONE COMPLETION TESTING

SOLVENT STANDALONE COMPLETION TESTING

SOLVENT STANDALONE COMPLETION TESTING

STANDALONE COMPLETION TESTING FOR INJECTOR

STANDALONE COMPLETION TESTING FOR INJECTOR

PRESSURE PULSATION TESTING

SLURRY STANDALONE COMPLETION TESTING RIGS

SLURRY STANDALONE COMPLETION TESTING RIGS

CASED AND PERFORATED STANDALONE COMPLETION TESTING

CASED AND PERFORATED STANDALONE COMPLETION TESTING

STANDALONE COMPLETION TESTING

HIGH PRESSURE/HIGH TEMPERATURE TESTING RIG

HIGH PRESSURE/HIGH TEMPERATURE TESTING RIG

PERFORATION TESTING RIG

PERFORATION TESTING RIG

WELLBORE SIMULATOR RIG

WELLBORE SIMULATOR RIG

NOZZLE TESTING RIG

NOZZLE TESTING RIG

SCREEN EROSION TESTING RIG

SCREEN EROSION TESTING RIG

BULK SCALE TESTING RIG

BULK SCALE TESTING RIG
proDRILL

proDRILL™

proDRILL™: Perforated Tubing and Casing

FET Variperm’s proDRILL™ perforated liner systems are a proficient and cost-effective way to establish communication between the reservoir and the well bore.

FEATURES & BENEFITS

  • High open area which provides a low-pressured drop and velocity across the liner
  • Ability to perforate any desired hole pattern, diameter, or phasing
  • No cost for wireline or tubing conveyed perforating

APPLICATIONS

  • Horizontal well bores as standalone systems or combined with swellable packers.
  • Horizontal well bores to provide hole consolidation where a cemented liner is not necessary.
  • Injection Wells
proDRILL

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to Downhole Sand Control
proWRAP

proWRAP®

proWRAP®: Wire-Wrapped Screen

FET Variperm’s proWRAP sand control device (SCD) is a direct or slip-on wire-wrapped screen positioned over top of a slotted or perforated base pipe.

FEATURES & BENEFITS

  • Large open flow area (5 to 20% or more)
  • Corrosion-resistant stainless steel (304L or 316L)
  • Plugging-resistant keystone profile
  • High-strength slotted or perforated basepipe
  • High flow rate with low-pressure drop

APPLICATIONS

  • Openhole standalone completions
  • Secondary liner completions
  • Cased and perforated completions
  • Horizontal, deviated, and vertical wells
  • Producer, injector, and infill wells
  • Ideal for medium to high velocity wells
proWRAP

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back To Downhole Sand Control
proPACK

proPACK®

proPACK®: Prepacked Screen

FET Variperm’s proPACK sand control device (SCD) is a slip on modular gravel pack system, with two outer screens, positioned over top of a perforated or slotted base pipe.

FEATURES & BENEFITS

  • Large open flow area (5 to 20% or more)
  • Corrosion-resistant stainless steel (304L or 316L)
  • Plugging-resistant keystone profile
  • High-strength slotted or perforated basepipe
  • High flow rate with low-pressure drop
  • High permeability

APPLICATIONS

  • Openhole standalone completions
  • Secondary liner completions
  • Cased and perforated completions
  • Horizontal, deviated, and vertical wells
  • Producer, injector, and infill wells
  • Ideal for high-velocity wells
proPACK

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to Downhole Sand Control
proPUNCH

proPUNCH®

proPUNCH®: Punch Screen

FET Variperm’s proPUNCH sand control device (SCD) is a slip-on punched screen positioned over top of a slotted or perforated base pipe.

FEATURES & BENEFITS

  • Large open flow area (2 to 8% or more)
  • Corrosion-resistant stainless steel (304L or 316L)
  • High-strength slotted or perforated basepipe
  • High flow rate with low-pressure drop

APPLICATIONS

  • Openhole standalone completions
  • Secondary liner completions
  • Cased and perforated completions
  • Horizontal, deviated, and vertical wells
  • Producer, injector, and infill wells
  • Ideal for medium to high velocity wells
proPUNCH

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to downhole sand control
proSLOT

proSLOT®

proSLOT®: Straight Slotted Liner

FET Variperm’s proSLOT straight-slotted liner sand control device (SCD) is manufactured to create a straight slot in the base pipe, reducing sand infiltration while maintaining superior mechanical strength and integrity.

FEATURES & BENEFITS

  • Patented thermal deburring technology
  • High-strength slotted liner
  • Economic straight slot
  • Flush OD with no outer screens

APPLICATIONS

  • Openhole standalone completions
  • Secondary liner completions
  • Cased and perforated completions
  • Horizontal, deviated, and vertical wells
  • Producer, injector, and infill wells
  • Ideal for low to medium velocity wells
proSLOT

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to Downhole Sand Control
proSEAM

proSEAM®

proSEAM®: Seamed-Slotted Liner

FET Variperm’s proSEAM slotted liner sand control device (SCD) is manufactured to create a “keystone” profile of each slot, reducing sand infiltration and plugging potential while maintaining superior mechanical strength and integrity.

FEATURES & BENEFITS

  • Patented thermal deburring technology
  • High-strength slotted liner
  • Plugging-resistant seamed slot keystone profile
  • Flush OD with no outer screens

APPLICATIONS

  • Openhole standalone completions
  • Secondary liner completions
  • Cased and perforated completions
  • Horizontal, deviated, and vertical wells
  • Producer, injector, and infill wells
  • Ideal for low to medium velocity wells
proSEAM

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to Downhole Sand Control
proMESH

proMESH®

proMESH®: Woven Metal Mesh Screen

FET Variperm’s proMESH is a cost-effective sand control solution that is designed to filter a high percentage of poorly sorted sands in unconsolidated formations. It consists of the base pipe – either slotted or perforated – support core, filter media, drainage layer, and protective shroud.

FEATURES & BENEFITS

  • Large open flow area (5 to 20% or more)
  • Corrosion-resistant stainless steel (304L or 316L)
  • Plugging-resistant keystone profile
  • High-strength slotted or perforated basepipe
  • High flow rate with low-pressure drop
  • Flexibility in design and production

APPLICATIONS

  • Openhole standalone completions
  • Secondary liner completions
  • Cased and perforated completions
  • Horizontal, deviated, and vertical wells
  • Producer, injector, and infill wells
  • Ideal for high velocity wells
proMESH

Contact our sand control experts to learn how we can unlock the potential of your reservoir at [email protected].

Back to Downhole Sand Control
